Apertadeira Crowfoot EA-LC
Especificações Técnicas
| Modelo | Rotação (rpm) | Capacidade de Torque | Distância lateral ao centro (mm) | Raio frotal do cabeçote (mm) | Espessura do cabeçote (mm) | Comprimento (mm) | Peso (kg) | Sextavado máximo (mm) | |
| (Nm) | (lb.ft) | ||||||||
| EA23LC8−16 | 730 | 5,0~16,0 | 3,5~12,0 | 13,0 | 13,0 | 16,0 | 453 | 1,5 | 13 |
| EA23LC69−15 | 820 | 4,5~15,0 | 3,5~11,0 | 16,0 | 13,5 | 16,0 | 498 | 2,2 | 13 |
| EA33LC69−27 | 905 | 8,0~27,0 | 6,0~20,0 | 16,0 | 13,5 | 16,0 | 523 | 2,2 | 13 |
| EA23LC379−30 | 410 | 9,0~30,0 | 6,5~22,0 | 16,0 | 13,5 | 15,0 | 460 | 1,6 | 13 |
| EA23LC246−20 | 640 | 6,0~20,0 | 4,5~15,0 | 16,0 | 16,0 | 20,5 | 499 | 2,2 | 13 |
| EA33LC246−38 | 710 | 12,0~38,0 | 9,0~28,0 | 16,0 | 16,0 | 20,5 | 524 | 2,4 | 13 |
| EA23LC13−18 | 720 | 5,5~18,0 | 4,0~13,0 | 16,0 | 13,5 | 20,5 | 498 | 2,2 | 13 |
| EA33LC13−30 | 795 | 9,0~30,0 | 6,5~22,0 | 16,0 | 13,5 | 20,5 | 523 | 2,4 | 13 |
| EA33LC800−27 | 905 | 8,0~27,0 | 6,0~20,0 | 16,0 | 13,5 | 20,5 | 502 | 2,3 | 13 |
| EA33LC29−35 | 685 | 10,5~35,0 | 8,0~26,0 | 20,5 | 20,5 | 14,0 | 527 | 2,5 | 19 |
| EA34LC29−45 | 530 | 13,5~45,0 | 10,0~33,0 | 20,5 | 20,5 | 14,0 | 570 | 2,6 | 19 |
| EA34LC10−49 | 445 | 15,0~49,0 | 11,0~36,0 | 20,5 | 20,5 | 28,0 | 610 | 3,4 | 19 |
| EA34LC10−88 | 360 | 26,0~88,0 | 20,0~65,0 | 20,5 | 20,5 | 28,0 | 635 | 3,4 | 19 |
